EC Buying Mini fuente de alimentación reducida, conmutación doméstica inteligente módulo de alimentación CC AC DC módulo de alimentación aislada de 220 V a 5 V, HLK PM01 convertidor de CA CC de 220 V a 5 V (3 piezas)
EC Buying Mini fuente de alimentación reducida, conmutación doméstica inteligente módulo de alimentación CC AC DC módulo de alimentación aislada de 220 V a 5 V, HLK PM01 convertidor de CA CC de 220 V a 5 V (3 piezas)
EC Buying Mini fuente de alimentación reducida, conmutación doméstica inteligente módulo de alimentación CC AC DC módulo de alimentación aislada de 220 V a 5 V, HLK PM01 convertidor de CA CC de 220 V a 5 V (3 piezas)
- ✔HLK-PM01: El último módulo de fuente de alimentación Hi-Link, adecuado para dispositivos de control de interruptor de hogar inteligente, volumen pequeño, baja corriente, rango de entrada de voltaje, es la mejor opción de hogar inteligente.
- ✔ Módulo de potencia aislado AC-DC: cumple con los requisitos UL, CE, ultrafino, ultra pequeño; entrada de voltaje completo (90 ~ 245 Vac); baja ondulación, bajo ruido; diseño del producto cumple con los requisitos de prueba de seguridad y EMC; bajo consumo de energía, protección del medio ambiente, pérdida de carga < 0,1 W; 100% envejecimiento de carga y pruebas
- ✔HLK-PM01: la fuente de alimentación del módulo de la serie ultra pequeña de 3W es una fuente de alimentación del módulo de alta eficiencia. Tiene las ventajas del rango de entrada de voltaje global, bajo aumento de temperatura, bajo consumo de energía, alta eficiencia, alta fiabilidad y alto aislamiento de seguridad. Ha sido ampliamente utilizado en hogares inteligentes, control de automatización, equipos de comunicación, instrumentación y otras industrias.
- ✔ Módulo de potencia aislado AC-DC: tiene buena protección contra cortocircuito y sobrecorriente y autorecuperación, alta eficiencia y alta densidad de potencia.
- ✔ El paquete incluye: 3 módulos de alimentación. (Módulo de potencia aislado AC-DC)
| Brand: | EC Buying |
|---|---|
| Color: | Negro |
| Manufacturer: | EC Buying |
| Part Number: | Z253MQ2 |
| Isin: | IEQXD1RPGVEL |
Out of Stock
In Stock
Backordered
Out of Stock
IBspot Buyer Protection
Shop confidently on IBspot, receive your item as described or your money back for eligible orders. Learn Program Terms
GUARANTEED SAFE CHECKOUT
-
MONEY BACK GUARANTEE
30 days money back guarantee, no additional fee charged.
-
EXCELLENT SUPPORT
We provide 24/7 online customer support via email.
-
Fast Shipping
One week domestic shipping. Global delivery to the US in 2 weeks.
Características:
√Ultradelgado, ultrapequeño, el volumen más pequeño de la industria.
√ entrada de voltaje universal (90 ~ 245 Vac).
√ Bajo consumo de energía, protección ambiental verde, pérdida de carga < 0,1 W.
√ Bajo ondulación, bajo ruido, no requiere circuito externo.
Buena protección contra cortocircuitos y sobrecorriente de salida, recuperación automática, alta eficiencia y alta densidad de potencia.
√ Aislamiento de entrada y salida soporta voltaje de 3000 Vac
√ Alta fiabilidad, diseño de larga vida, tiempo de trabajo continuo es de más de 100.000 horas.
√Cumple con los requisitos de UL y CE; el diseño del producto cumple con los requisitos de pruebas de seguridad y EMC. √ Envases de pegamento termoconductivo impermeable y respetuoso con el medio ambiente, a prueba de humedad, antivibración, en línea con las normas IP65 impermeables y a prueba de polvo.
Parámetros:
※ entrada de voltaje nominal: 100-240 VAC; rango de entrada de voltaje: 90-264 VAC.
※Corriente máxima de entrada: ≤0.2A; corriente de sobretensión de entrada: ≤10A
※ Voltaje máximo de entrada: ≤270 VCA
※Entrada de arranque lento: ≤50 mS.
※ Eficiencia de entrada de bajo voltaje: Vin= 110VAc, carga completa ≥ 69%; eficiencia de entrada de alto voltaje: Vin=220VAc, carga completa ≥ 70%
Fiabilidad a largo plazo: MTBF≥100.000 h.
Voltaje de salida nominal sin carga: 5±0.1VDC; voltaje de salida nominal de carga completa: 5±0.2VCC.
※Límite de corriente de salida a corto plazo: ≥1000mA; límite de salida a largo plazo: ≥600mA
Regulación de voltaje: ±0,2%; Regulación de carga: ±0,5%
※Ondulación y ruido de salida (mVp-p): ≤50 mV, entrada de voltaje nominal, salida completa. Probado con osciloscopio de ancho de banda de 20 MHz, lado de carga y condensadores de 10 uF y 0,1 uF.
Rango de sobrecarga de la máquina de conmutación: (entrada de voltaje nominal, salida más 10% de carga) ≤ 5% VO.
Protección contra sobrecorriente de salida: 150-200 A es el límite de carga de salida.
Protección contra cortocircuito de salida: cortocircuito directo durante la salida normal, y reanudar automáticamente el funcionamiento normal después de cortocircuito.
