autoutdoor For 2002-03 Oldsmobile Bravada 14x Front Wheel Bearning Hub Sway Bar Ball Joint
autoutdoor For 2002-03 Oldsmobile Bravada 14x Front Wheel Bearning Hub Sway Bar Ball Joint
2x Front Upper Ball Joint -K6664
2x Front Lower Ball Joint -K6663
1x Rear Sway Bar End Link - Passenger Side -K6667
1x Rear Sway Bar End Link - Driver Side -K6668
1x Front Outer Tie Rod End - Driver Side -ES3675
1x Front Outer Tie Rod End - Passenger Side -ES3676
2x Front Inner Tie Rod End -EV80965
1x Front Sway Bar End Link - Passenger Side -K6665
1x Front Sway Bar End Link - Driver Side -K6666
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1.Fitting the Following vehicle:
2002-2003 Chevrolet Trailblazer2002-2003 Chevrolet Trailblazer EXT
2002-2003 GMC Envoy
2002-2003 GMC Envoy XL
2003 Isuzu Ascender
2002-2003 Oldsmobile Bravada
2.Package Includes:
2x Front Wheel Hub Bearing -5131882x Front Upper Ball Joint -K6664
2x Front Lower Ball Joint -K6663
1x Rear Sway Bar End Link - Passenger Side -K6667
1x Rear Sway Bar End Link - Driver Side -K6668
1x Front Outer Tie Rod End - Driver Side -ES3675
1x Front Outer Tie Rod End - Passenger Side -ES3676
2x Front Inner Tie Rod End -EV80965
1x Front Sway Bar End Link - Passenger Side -K6665
1x Front Sway Bar End Link - Driver Side -K6666
Tie-Rod End Replacement Guideline:
If you feel a bump in the steering when driving over road bumps or curbs, this might be due to worn tie rod ends or inner tie rods. Clicking noises during sudden steering movements can also be symptoms of a defective tie rod. In order to determine the exact cause and replace the defective tie rod, the car must be elevated with a vehicle lift in order to be examined more closely.
This useful tip applies to the exchange of tie rod ends and inner tie rods, which together form the so-called tie rod.
Picture(A)
Note: Cleanliness is extremely important when working on the power steering. Incorrect work and contamination can lead to leakage and, in the worst case, to failure of the steering assistance.
1.Lift the vehicle and dismount the front axle wheels.
2.Spray the fastening nut of the tie rod end with rust remover and leave it on for a few minutes.
Picture(B)
3.Dismount the front underride guard.
Picture(C)
4.Loosen the fastening nut from the tie rod and remove it completely.
5.Remove the tie rod end from the steering knuckle using an appropriate ball joint separator.
Picture(D)
6.Remove the clamp of the bellow on the steering gear.
7.Push the bellow towards the tie rod end.
Picture(E)
8.Unscrew the inner tie rod from the rack.
9.Clean the sealing face of the bellow at the steering gear.
Picture(F)
10.Clean the lug of the rubber contact surface of the ball joint in the steering knuckle.
Note:Always use new self-locking nuts and bolts for a reliable repair.
11.Screw the new inner tie rod into the rack and tighten it with the tightening torque that has been specified by the vehicle manufacturer.
Picture(G)
12.Mount the bellow and close the clamps with the appropriate special tool.
Note:Incorrect mounting of the bellow can lead to corrosion of the rack: the steering gear starts leaking which can lead to a failure in the steering assistance.
Picture(H)
13.Secure the ball joint in the steering knuckle and mount the nut. Please observe the tightening torque suggested by the vehicle manufacturer.
Note:During mounting, the ball stud should not turn within the ball joint. This can cause damage inside the ball joint and can lead to early failure.
Tip:Secure the ball stud against twisting with a suitable tool.
Picture(I)
14.Mount the front underride guard.
15.Mount the front wheels and tighten them with the tightening torque recommended by the vehicle manufacturer.
16.Align the wheels and adjust them if necessary. Observe the vehicle manufacturer specifications.
17.Perform a test drive.
Note:When performing the test drive, pay special attention to the handling while cornering and listen for possible noise emission.
Ball Joint Replacement Guideline:
If there is a knocking or clunking noise in the area of the front axle when the car is traveling over road bumps, potholes or curbs, then there is usually a defect in a component of the wheel suspension.
Picture(A)
The side of the front axle from which the (vibration) noise is emanating can already be determined during a test drive. The type of noise also already provides certain indications for maintenance regarding which components might be faulty.
Picture(B)
1.Raise the vehicle and remove the front wheels.
2.To loosen the fastening screws and fixing nuts of the compression ball joint more easily, spray them with rust remover and allow to act for a few minutes.
Picture(C)
3.Loosen the fastening screws of the broken ball joint on the control arm and remove the nuts.
Picture(D)
4.Loosen and remove the fixing nut of the ball joint on the steering knuckle.
Tip:If the ball stud rotates, hold the ball stud in place with a hexagon socket.
Picture(E)
5.Remove the bad or worn ball joint from the control arm.
6.Loosen the compression ball joint on the steering knuckle using a suitable special tool.
Picture(F)
7.Clean the cone connection.
Tip:For better sealing and durability of the ball joint sleeve, a little silicone grease can be applied to the contact surface.
Picture(G)
8.Insert new compression ball joint in the control arm and steering knuckle and tighten with new fixing nuts.
9.Reinstall front wheels. Lower the vehicle and tighten the wheel studs to the tightening torque specified by the vehicle manufacturer.
10.Measure the chassis and adjust it using the various holes on the compression ball joint if necessary.
11.Finally, carry out a test drive.
Sway Bar Stabilizer Link Replacement Guideline:
While driving, the following signs may indicate a faulty sway bar stabilizer link:
(1).Rattling and thumping noises on rough roads.
(2).Imprecise vehicle handling.
(3).Stronger inclination of the vehicle during cornering.
If the sway bar stabilizer link is found to be defective, it should be replaced as described below.
Picture(A)
1.Raise vehicle and remove front wheels.
Tip:Always check both stabilizer links and replace them in pairs if necessary.
2.Spray fastening nuts of the stabilizer link with rust remover and let act for a few minutes.
Picture(B)
3.Loosen the lower fastening nut of the stabilizer link at the stabilizer and remove.
Tip:If the ball stud also starts to turn, hold it with a suitable tool.
4.Press stabilizer link out of torsion bar.
Picture(C)
5.Loosen the upper fastening nut of the stabilizer link at the suspension strut and remove it.
Tip:If the ball stud also starts to turn, hold it with a suitable tool.
Picture(D)
6.Press stabilizer link at suspension strut out of bracket.
Picture(E)
7.Insert new stabilizer link at suspension strut.
Picture(F)
8.Tighten stabilizer link at suspension strut to the tightening torque specified by the vehicle manufacturer.
Tip:Secure the ball stud against twisting with a suitable tool.
Picture(G)
9.Insert new stabilizer link at stabilizer.
10.Tighten stabilizer link at stabilizer to the tightening torque specified by the vehicle manufacturer.
Tip:Secure the ball stud against twisting with a suitable tool.
Picture(H)
11.Remount the front wheels. Lower the vehicle and tighten the wheel studs to the tightening torque specified by the vehicle manufacturer.
Tip:Even if replacing the stabilizer link does not directly affect the chassis setting, we recommend checking the axle setting and adjusting if necessary after working on the suspension.
12.Conclude with a test drive.
Item Specifics | |
---|---|
Brand : | autoutdoor |
Type : | Sway Bar Link |
Universal Fitment : | No |
Included Hardware : | Mounting Hardware |
Performance Part : | No |
Interchange Part Number : | 513188,K6664,K6663,K6667,K6668,ES3675,ES3676,EV80965,K6665,K6666 |
Superseded Part Number : | stabilizer bar linkage,wheel hub bearing assembly,hubs bearings |
OE/OEM Part Number : | rods ends,car tie rod end replacement,anti sway bar,anti roll bar |
Finish : | Coated |
Manufacturer Warranty : | 10 Year |
Placement on Vehicle : | Front Upper Lower Rear Right Left Outer Inner |
Manufacturer Part Number : | ADD84104702R |
Adjustable : | Yes |
Material : | Alloy Steel |
Kit or Single Part : | Kit |
Greasable or Sealed : | Greasable |
OE Spec or Performance/Custom : | OE Spec |
Surface Finish : | Polished, Rust Protected |
Quantity : | 14Pcs |
Items Included : | Mounting Hardware |
ABS Sensor : | Has ABS with tegral Sensor |
Bolt Circle Diameter : | 16.666665cm |
